X/Y/Z Travel: 650x450x350mm
Worktable size: 800x550mm
Working tank size: 1050x700x400
Machine Dimension: 2200x2400x2840mm
Widely used in making:
2W/3W/4W Molds / Bumper / Grille Fender
A/B/C/ D Pillar / Door panel / Dashboard Household Molds / Furniture Molds Aerospace Military area / 3C molds
Product Details
| Worktable size(LxW) | 800x550mm |
| Travel(X/Y/Z) | 650x450x350mm |
| Working tank size(LxWxH) | 1050x700x400mm |
| Max. electrode weight | 80kg |
| Max. workpiece weight | 1500kg |
| Electrode holder to worktable distance | 250-600mm |
| Oil tank capacity | 600L |
| Filter precision | 5um |
| Machine weight | 6000kg |
| Machine dimension(LxWxH) | 2200x2400x2840mm |
System Main Function
* Latest WINDOWS base operation system
* Intelligent positioning function
* High speed AJC tool lifting
* Auto centering
* Accurate conpensation
* Automatic memory fuction
* Power reset
* Expert data base
* Different type orbinting function
* User-friendly
